KWD

5W - 15W Compact AC-DC PCB-Mount Power Supplies

The mature KWD dual output, pcb mount power supplies have field proven reliability. The series is available in 5W, 10W and 15W power levels with either +/-12V or +/-15V output voltages.  The KWD series requires no earth ground connection due to its double insulation construction.

KWD

Features

  • Small size and lightweight
  • PC Board Mountable
  • -10 to +70 °C Continuous Operation
  • 85 - 265VAC Wide Range Input
  • Convection Cooled
  • Low Noise Conducted EMI Class B

Downloads

Product Range Information

Hide details

Show details

To request a sample or quote, please tick the box alongside the model of interest.

Models selected: 0 Request quote / sample

Part number Power Output info Construction Status Stock Level Datasheet Request quote / sample
KWD 5-1212 5.2W 12V / 0.22A
-12V / 0.22A
Enclosed pcb mount Not recommended for new designs Enquire   Datasheet
KWD 10-1212 10.8W 12V / 0.45A
-12V / 0.45A
Enclosed pcb mount Not recommended for new designs Check stock   Datasheet
KWD 15-1212 15.6W 12V / 0.65A
-12V / 0.65A
Enclosed pcb mount Not recommended for new designs Enquire   Datasheet
KWD 5-1515 5.4W 15V / 0.18A
-15V / 0.18A
Enclosed pcb mount Not recommended for new designs Enquire   Datasheet
KWD 10-1515 10.8W 15V / 0.36A
-15V / 0.36A
Enclosed pcb mount Not recommended for new designs Enquire   Datasheet
KWD 15-1515 15.6W 15V / 0.52A
-15V / 0.52A
Enclosed pcb mount Not recommended for new designs Enquire   Datasheet
Part number
KWD 5-1212
Power 5.2W
Output info 12V / 0.22A
-12V / 0.22A
Construction Enclosed pcb mount
Status Not recommended for new designs
Stock Level Enquire
Datasheet Datasheet
Request quote / sample
KWD 10-1212
Power 10.8W
Output info 12V / 0.45A
-12V / 0.45A
Construction Enclosed pcb mount
Status Not recommended for new designs
Stock Level Check stock
Datasheet Datasheet
Request quote / sample
KWD 15-1212
Power 15.6W
Output info 12V / 0.65A
-12V / 0.65A
Construction Enclosed pcb mount
Status Not recommended for new designs
Stock Level Enquire
Datasheet Datasheet
Request quote / sample
KWD 5-1515
Power 5.4W
Output info 15V / 0.18A
-15V / 0.18A
Construction Enclosed pcb mount
Status Not recommended for new designs
Stock Level Enquire
Datasheet Datasheet
Request quote / sample
KWD 10-1515
Power 10.8W
Output info 15V / 0.36A
-15V / 0.36A
Construction Enclosed pcb mount
Status Not recommended for new designs
Stock Level Enquire
Datasheet Datasheet
Request quote / sample
KWD 15-1515
Power 15.6W
Output info 15V / 0.52A
-15V / 0.52A
Construction Enclosed pcb mount
Status Not recommended for new designs
Stock Level Enquire
Datasheet Datasheet
Request quote / sample
Key : Not recommended for new designs
